Ultrasonic Pachymeter and Biometer for Ophthalmology

CE & FDA registerd


Ophthalmic Ultrasonic Pachymeter and Biometer

Specifications:

Pachymeter
P Probe with 20MHz
Resolution: 1um
Measuring Range: 230 ~ 1200um
Multiple Corneal Maps
Built-in Patient Archive
Built-in Thermal Printer
Touch Screen & LCD Screen Display


 A-BIOMETER
 Probe: 10MHz with Fixation Red Light
 Total Gain: 100dB with an adjustable range of 0 ~ 50dB
 Biometry Accuracy: ≤±0.06mm
 Resolution: 0.01mm
 Measuring Range: 14 ~ 41mm
 Measuring Mode: Contact, Immersion
 Measuring Parameters: Anterior Chamber Depth, Lens Thickness, Vitreous Length, Axial Length
 5 Different Measuring Modes: Automatic (for Normal, Dense Cataract, Aphakic and Pseudo-aphakic) & Manual
 8 Groups of Readings for Average, SD
 IOL Formula: SRK/T, SRK-II, BINKHOST- II, HOLLADAY, HOFFER-Q and HAIGIS
