Ophthalmic Equipment Digital Eye Fundus Camera & FFA SK-650B
Features:
1.Reduce the pain and inconvenience of patient
2.Save time for patients and doctors,dilating need about 20 minutes
3.Won't affect patients' activity which improving their compliance
4.Non-mydriatic image with reliable quality
5.45° full-circle design
6.Switching anterior-posterior,para-position compensation lens
7.Split-line aligning focus
8.Exposure intensity automatic control
Technical Specification:
Features:
1.Reduce the pain and inconvenience of patient
2.Save time for patients and doctors,dilating need about 20 minutes
3.Won't affect patients' activity which improving their compliance
4.Non-mydriatic image with reliable quality
5.45° full-circle design
6.Switching anterior-posterior,para-position compensation lens
7.Split-line aligning focus
8.Exposure intensity automatic control
Technical Specification:
| Model | SK-650B |
| Optical lens | Aspherics system |
| Test mode | Non-mydriatic and FFA |
| Fundus Observation | Moved platform |
| Red-Free | No |
| Focus | Split-line aligning focusing |
| Digital Camera | CANON EOS Technology |
| Color Image Resolution | 5184*3456 |
| Monochrome Image resolution | 1360*1024 |
| Min.Pupil Size | 3.3mm |
| Compensation range | -25D~+30D |
| Fundus Observation para-position indication | Dots overlap |
| Fixation target | External eye fixation lamp & 9 internal fixation target (LED dot matrix-Fully controlled by software) |
| Maximum angle of view | 53° |
| Optical head tilting | Horizontal±30° Vertical±12.5° |
| Working distance | 40mm±2mm |
| software | Support Dicom 3.0, support hospital HIS/PACS system Image processing easily operate, strong analysis, support fundus Mosaic, image post processing, measurement, patient profile management |
