Solution Advice:   Installation &. Operation Guide.

You can provide us the water sources, water quality, flow rate and ground area, material requirements about your project, then more technical solutions will be suggested to you.

Why choose us

1. We consistent good quality with reasonable price.
2. Big company, good reputation, more reliable.
3. Delivery in time.
4. Over 15 years' experience since 2006.
5.Considerable after-sales service.

Our Services

 1.24-hour a day, 365-day a year access to a toll-free health care professional hotline for questions and trouble-shooting assistance FREELY.
2.all year round on site installation and debugging service abroad with professional engineer guide and training.

Packaging & Delivery

Packaging Details  Seaworthy package
Delivery Time      Within 20 days after receipt of deposit


Description

This is a kind of machine that combine MBR membrane separation technology with biological treatment technology and intelligent control technology.It features compact design,aesthetic appearance,small area,low cost,reliable operation,high automation as well as simple maintenance while discards defects in traditional sewage treatment technology.Secondary sedimentation tank was replaced and reclaimed water can be obtained through effective solid-liquid separation.It also boasts high concentrated microbial biomass in biological tank,less excess sludge,effective removal of ammonia nitrogen,near zero suspended substance in the effluent and turbidity,elimination of bacteria and virus to a great extend and effluent qually is much better than reclaimed water quality (exceeds national first level standard A. This system is suitable for waste water treatment of residence communities,offices,commercial buildings,hotels,restaurants,schools,hospital,high ways,railways,factories ect. as well as for industries like slaughter,textile,beer,paper mill,leather,food,chemicals etc. Specifications we produce are as follows:5t/d,25t/d,50t/d,100t/d,150t/d,200t/d,300t/d,500t/d(manufacture according to client's requirement).



MBR  as a waste water treatment system features simple operation,high automation and modular design,it also has below advantages:
1.Save 50% occupying area compared with traditional system.
2.Relative high MLSS value(<15g/L) and long residue time  for sludge(<60days).
3.Stable producing water quality for different inlet water.
4.Less sludge residue reduces cost for sludge treatment.
5.Low energy consumption,simple cleaning and low operation cost.


Technological Process:
Sewage → Grille → Regulating pond → MBR Bioreactor → Discharge(reuse)
 1. Temperature: 5ºC~45ºC, average membrane aperture 0.10 μm.
2. PH: 2~12, membrane thickness: 40μm.
3. Outlet water turbidity: <1 NTU , outlet water SS <1mg/L.
4. Membrane area: 8m2, advised gas-water ratio: 25:1~30:1.
5. Operating pressure: -0.01 ~ -0.03MPa.

Features:

1. Because of the high-efficiency solid-liquid separation, it can efficiently remove the SS, colloidal material and dead microbe in the sewage, no need sedimentation tank, or filter device, nor other solid-liquid separation device.
2. The MBR can make the biomass in biological treatment unit maintain high concentration, thus highly improve the volume loading. Meanwhile, the high efficient membrane separation can shorten the HRT. The device is with a compact structure and small space occupation.
3. MBR can filter out bacteria, part of the harmful material such as virus, it can obviously save dosing disinfection dosage, greatly improve the quality of the output water and reduce the operating cost and widen the scope of application of water.
4. Due to the strong interception function of MBR, it can keep the microbe in the reactor to avoid the loss of all kinds of microbe groups, which is good for the growth of the bacteria (such as the nitrifying bacteria), at the same time, it can lengthen the residence time of difficult degradable macromolecule organics to improve the decomposition so as to make the metabolic system process smoothly. The system has a strong impact resistance and wide suitability.
5. It can realize the completely separation of HRT and SRT. By the extended aeration, it can consume the organics, it can theoretically achieve the effect of no excess sludge emissions, thus reduce the surplus sludge treatment costs significantly.
6. The unique mode of operation makes the membrane surface no blocking, and the cleaning interval time is long. The way to clean the membrane is easy, since the membrane module can be separately cleaned, thus, the maintenance is convenience and simple.
The module design make the machine flexible, it is easy to expand the volume.







FAQ

1.Q:Are you a factory or trading company?
  A: We are a factory, we have rich experience for manufacturing water processing equipment for more than 13 years.

2.Q:Where is your factory located? How can i visit there?
  A:  Our factory is located in No.1137, Zhucheng city, Shandong Province, China. It is about 2 hours from Qingdao airport. We can pick you up if you need, welcome to visit our factory.

3.Q: Do you have  minimum order quantity request?
  A: No minimum order, but it can get a discount if you order a large quantity.

4.Q: Do you have  certificates?
  A: Yes, we have ISO,SGS certificate.

5.Q: Can you meet my special requirements for my products?
  A: Yes, we have a professional design team. We can provide drawings according to your requirements.

6. Q:How to buy your idea products?
   A:You can provide us your water sources, water quality, flow rate and ground area (contact us for more details).

7. Q:How to pay?
  A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balance before loading by TT.

8. Q:What is the delivery time?
  A: It depends on order quantities. Generally speaking, the delivery time will be within 4 to 6 weeks.

9. Q: How to pack the products?
  A: We use standard package. If you have special package requirements, we will pack as required, but the fees will be paid by customers.

10. Q: How to keep your equipments from corrosion?
    A: We use the world-famous paint, like SigmaCoatings, PainBow,etc. What's more, we paint strictly according to the standard process.

11. Q: How do you manufacture your equipment ?
    A:Our  machining technology  includes laser/plasma cutting, automatic welding,CNC cutting and bending.

12. Q:How to install after the equipments arriving destination?
    A: We will provide detailed illustrations to you. If it is necessary, we will send technicians to help you. However, the visa fee, air tickets, accommodation, wages will be paid by buyers.
