Ce FDA Hand Held Portable Digital Slit Lamp
Converging Optics Design
Three Magnifications (10X, 16X and 25X) with Different Eyepieces
Main Mirrors Use Imported Material. All Mirrors Have Been Carried out Moisture Proof,
Mould Proof and Coating
Processing for Many Times, Which Prove Its Good Optic Performance in Different
Weather Condition German Industrial Bulb, High-Lightness without Harsh, Quick Heat Dispersion
One Piece Preset Lens and One Diffuse Lens for Free
International Standard Accessory Interface Which Can Connect Kinds of Laser Adapter .
and Goldman Tonometer
Converging Optics Design
Three Magnifications (10X, 16X and 25X) with Different Eyepieces
Main Mirrors Use Imported Material. All Mirrors Have Been Carried out Moisture Proof,
Mould Proof and Coating
Processing for Many Times, Which Prove Its Good Optic Performance in Different
Weather Condition German Industrial Bulb, High-Lightness without Harsh, Quick Heat Dispersion
One Piece Preset Lens and One Diffuse Lens for Free
International Standard Accessory Interface Which Can Connect Kinds of Laser Adapter .
and Goldman Tonometer
| Model | WHY-J5E2 |
| Microscope Type | Converging |
| Digital System | No |
| Magnification Change Way | Deflector Rod |
| Eyepiece Magnification | 10x 16x |
| Total Magnifications | 10x 16x 25x |
| Diopter Adjustment | -5D ~+5D |
| Illumination | Three Steps (5 Steps and Step less Optional) |
| Slit Width | 0-14MM Continuous |
| Slit Height | 1-14MM Continuous |
| Slit Angle | 0°- 180° Adjustable |
| Slit Inclination Angle | 5° 10° 15° 20° |
| Light Source | High Light Source |
| Light Spot Diameter | Φ0.2mm, Φ2mm, Φ3mm, Φ5mm, Φ10mm, Φ14mm |
| Filter | Heat Absorption; Grey; Redfree; Cobalt Blue |
| Fixation | Red LED |
| Electrical | |
| Illumination Bulb | German OSRAM Halogen Tungsten Lamp |
| Input Voltage | 110V/220V (±10%) |
| Input Power | 60VA |
| Diffuse Lens | Yes |
| Preset Lens | Yes |
| Laser Interface | Yes |
